### Correlation

####
The correlation is one of the most common and most useful statistics. A correlation is a single number that describes the degree of relationship between two variables. Let's work through an example to show you how this statistic is computed.

## Correlation Example

####
Let's assume that we want to look at the relationship between two variables, height (in inches) and self esteem. Perhaps we have a hypothesis that how tall you are effects your self esteem (incidentally, I don't think we have to worry about the direction of causality here -- it's not likely that self esteem causes your height!). Let's say we collect some information on twenty individuals (all male -- we know that the average height differs for males and females so, to keep this example simple we'll just use males). Height is measured in inches. Self esteem is measured based on the average of 10 1-to-5 rating items (where higher scores mean higher self esteem). Here's the data for the 20 cases (don't take this too seriously -- I made this data up to illustrate what a correlation is):
**Person****Height****Self Esteem**
1 68 4.1
2 71 4.6
3 62 3.8
4 75 4.4
5 58 3.2
6 60 3.1
7 67 3.8
8 68 4.1
9 71 4.3
10 69 3.7
11 68 3.5
12 67 3.2
13 63 3.7
14 62 3.3
15 60 3.4
16 63 4.0
17 65 4.1
18 67 3.8
19 63 3.4
20 61 3.6

Now, let's take a quick look at the histogram for each variable:
And, here are the descriptive statistics:
**Variable****Mean****StDev****Variance****Sum****Minimum****Maximum****Range**
Height 65.4 4.40574 19.4105 1308 58 75 17
Self Esteem 3.755 0.426090 0.181553 75.1 3.1 4.6 1.5

Finally, we'll look at the simple bivariate (i.e., two-variable) plot:
You should immediately see in the bivariate plot that the relationship between the variables is a positive one (if you can't see that, review the section on types of relationships) because if you were to fit a single straight line through the dots it would have a positive slope or move up from left to right. Since the correlation is nothing more than a quantitative estimate of the relationship, we would expect a positive correlation.
What does a "positive relationship" mean in this context? It means that, in general, higher scores on one variable tend to be paired with higher scores on the other and that lower scores on one variable tend to be paired with lower scores on the other. You should confirm visually that this is generally true in the plot above.

Person | Height | Self Esteem |

1 | 68 | 4.1 |

2 | 71 | 4.6 |

3 | 62 | 3.8 |

4 | 75 | 4.4 |

5 | 58 | 3.2 |

6 | 60 | 3.1 |

7 | 67 | 3.8 |

8 | 68 | 4.1 |

9 | 71 | 4.3 |

10 | 69 | 3.7 |

11 | 68 | 3.5 |

12 | 67 | 3.2 |

13 | 63 | 3.7 |

14 | 62 | 3.3 |

15 | 60 | 3.4 |

16 | 63 | 4.0 |

17 | 65 | 4.1 |

18 | 67 | 3.8 |

19 | 63 | 3.4 |

20 | 61 | 3.6 |

Variable | Mean | StDev | Variance | Sum | Minimum | Maximum | Range |

Height | 65.4 | 4.40574 | 19.4105 | 1308 | 58 | 75 | 17 |

Self Esteem | 3.755 | 0.426090 | 0.181553 | 75.1 | 3.1 | 4.6 | 1.5 |

## Calculating the Correlation

####
Now we're ready to compute the correlation value. The formula for the correlation is:
We use the symbol **r** to stand for the correlation. Through the magic of mathematics it turns out that r will always be between -1.0 and +1.0. if the correlation is negative, we have a negative relationship; if it's positive, the relationship is positive. You don't need to know how we came up with this formula unless you want to be a statistician. But you probably will need to know how the formula relates to real data -- how you can use the formula to compute the correlation. Let's look at the data we need for the formula. Here's the original data with the other necessary columns:

**r**to stand for the correlation. Through the magic of mathematics it turns out that r will always be between -1.0 and +1.0. if the correlation is negative, we have a negative relationship; if it's positive, the relationship is positive. You don't need to know how we came up with this formula unless you want to be a statistician. But you probably will need to know how the formula relates to real data -- how you can use the formula to compute the correlation. Let's look at the data we need for the formula. Here's the original data with the other necessary columns:

Person | Height (x) | Self Esteem (y) | x*y | x*x | y*y |

1 | 68 | 4.1 | 278.8 | 4624 | 16.81 |

2 | 71 | 4.6 | 326.6 | 5041 | 21.16 |

3 | 62 | 3.8 | 235.6 | 3844 | 14.44 |

4 | 75 | 4.4 | 330 | 5625 | 19.36 |

5 | 58 | 3.2 | 185.6 | 3364 | 10.24 |

6 | 60 | 3.1 | 186 | 3600 | 9.61 |

7 | 67 | 3.8 | 254.6 | 4489 | 14.44 |

8 | 68 | 4.1 | 278.8 | 4624 | 16.81 |

9 | 71 | 4.3 | 305.3 | 5041 | 18.49 |

10 | 69 | 3.7 | 255.3 | 4761 | 13.69 |

11 | 68 | 3.5 | 238 | 4624 | 12.25 |

12 | 67 | 3.2 | 214.4 | 4489 | 10.24 |

13 | 63 | 3.7 | 233.1 | 3969 | 13.69 |

14 | 62 | 3.3 | 204.6 | 3844 | 10.89 |

15 | 60 | 3.4 | 204 | 3600 | 11.56 |

16 | 63 | 4 | 252 | 3969 | 16 |

17 | 65 | 4.1 | 266.5 | 4225 | 16.81 |

18 | 67 | 3.8 | 254.6 | 4489 | 14.44 |

19 | 63 | 3.4 | 214.2 | 3969 | 11.56 |

20 | 61 | 3.6 | 219.6 | 3721 | 12.96 |

Sum = | 1308 | 75.1 | 4937.6 | 85912 | 285.45 |

The first three columns are the same as in the table above. The next three columns are simple computations based on the height and self esteem data. The bottom row consists of the sum of each column. This is all the information we need to compute the correlation. Here are the values from the bottom row of the table (where N is 20 people) as they are related to the symbols in the formula:

Now, when we plug these values into the formula given above, we get the following (I show it here tediously, one step at a time):

So, the correlation for our twenty cases is .73, which is a fairly strong positive relationship. I guess there is a relationship between height and self esteem, at least in this made up data!

Positive and Negative Correlations

**I pointed out above that a correlation can vary from +1.00 to –1.00. The correlation we just computed is a positive correlation. That is, high reading scores go with high math scores, low with low, and so on. However, we could have a negative correlation. This is not something bad; it simply denotes an association in which high scores on one variable go with low scores on the other. For example, if we were computing a correlation between, say, amount of time students watch television and their achievement score, we would find a negative correlation: high TV watching is associated with lower achievement scores, and vice versa. Such a correlation might be something like –.71.**

# Types of Correlation

#### Positive Correlation

####
**
Positive correlation occurs when an increase in one variable increases the value in another.
The line corresponding to the scatter plot is an increasing line.
**

**
**

Positive correlation occurs when an increase in one variable increases the value in another.

The line corresponding to the scatter plot is an increasing line.

#### Negative Correlation

####
**
Negative correlation occurs when an increase in one variable decreases the value of another.
The line corresponding to the scatter plot is a decreasing line.
**

**
**

Negative correlation occurs when an increase in one variable decreases the value of another.

The line corresponding to the scatter plot is a decreasing line.

#### No Correlation

####
**
No correlation occurs when there is no linear dependency between the variables.
**

**
**

No correlation occurs when there is no linear dependency between the variables.

#### Perfect Correlation

####
**
Perfect correlation occurs when there is a funcional dependency between the variables.
In this case all the points are in a straight line.
**

**
**

Perfect correlation occurs when there is a funcional dependency between the variables.

In this case all the points are in a straight line.

#### Strong Correlation

####
**
A correlation is stronger the closer the points are located to one another on the line.
**

**
**

A correlation is stronger the closer the points are located to one another on the line.

#### Weak Correlation

####
**
A correlation is weaker the farther apart the points are located to one another on the line.
**

**
**

A correlation is weaker the farther apart the points are located to one another on the line.

## Testing the Significance of a Correlation

####
Once you've computed a correlation, you can determine the probability that the observed correlation occurred by chance. That is, you can conduct a significance test. Most often you are interested in determining the probability that the correlation is a real one and not a chance occurrence. In this case, you are testing the mutually exclusive hypotheses:
Null Hypothesis: r = 0
Alternative Hypothesis: r <> 0

The easiest way to test this hypothesis is to find a statistics book that has a table of critical values of r. Most introductory statistics texts would have a table like this. As in all hypothesis testing, you need to first determine the significance level. Here, I'll use the common significance level of alpha = .05. This means that I am conducting a test where the odds that the correlation is a chance occurrence is no more than 5 out of 100. Before I look up the critical value in a table I also have to compute the degrees of freedom or df. The df is simply equal to N-2 or, in this example, is 20-2 = 18. Finally, I have to decide whether I am doing a one-tailedor two-tailed test. In this example, since I have no strong prior theory to suggest whether the relationship between height and self esteem would be positive or negative, I'll opt for the two-tailed test. With these three pieces of information -- the significance level (alpha = .05)), degrees of freedom (df = 18), and type of test (two-tailed) -- I can now test the significance of the correlation I found. When I look up this value in the handy little table at the back of my statistics book I find that the critical value is .4438. This means that if my correlation is greater than .4438 or less than -.4438 (remember, this is a two-tailed test) I can conclude that the odds are less than 5 out of 100 that this is a chance occurrence. Since my correlation 0f .73 is actually quite a bit higher, I conclude that it is not a chance finding and that the correlation is "statistically significant" (given the parameters of the test). I can reject the null hypothesis and accept the alternative.

Null Hypothesis: | r = 0 |

Alternative Hypothesis: | r <> 0 |

## The Correlation Matrix

####
All I've shown you so far is how to compute a correlation between two variables. In most studies we have considerably more than two variables. Let's say we have a study with 10 interval-level variables and we want to estimate the relationships among all of them (i.e., between all possible pairs of variables). In this instance, we have 45 unique correlations to estimate (more later on how I knew that!). We could do the above computations 45 times to obtain the correlations. Or we could use just about any statistics program to automatically compute all 45 with a simple click of the mouse.
I used a simple statistics program to generate random data for 10 variables with 20 cases (i.e., persons) for each variable. Then, I told the program to compute the correlations among these variables. Here's the result:
** C1 C2 C3 C4 C5 C6 C7 C8 C9 C10
C1 1.000
C2 0.274 1.000
C3 -0.134 -0.269 1.000
C4 0.201 -0.153 0.075 1.000
C5 -0.129 -0.166 0.278 -0.011 1.000
C6 -0.095 0.280 -0.348 -0.378 -0.009 1.000
C7 0.171 -0.122 0.288 0.086 0.193 0.002 1.000
C8 0.219 0.242 -0.380 -0.227 -0.551 0.324 -0.082 1.000
C9 0.518 0.238 0.002 0.082 -0.015 0.304 0.347 -0.013 1.000
C10 0.299 0.568 0.165 -0.122 -0.106 -0.169 0.243 0.014 0.352 1.000**

This type of table is called a *correlation matrix*. It lists the variable names (C1-C10) down the first column and across the first row. The diagonal of a correlation matrix (i.e., the numbers that go from the upper left corner to the lower right) always consists of ones. That's because these are the correlations between each variable and itself (and a variable is always perfectly correlated with itself). This statistical program only shows the lower triangle of the correlation matrix. In every correlation matrix there are two triangles that are the values below and to the left of the diagonal (lower triangle) and above and to the right of the diagonal (upper triangle). There is no reason to print both triangles because the two triangles of a correlation matrix are always mirror images of each other (the correlation of variable x with variable y is always equal to the correlation of variable y with variable x). When a matrix has this mirror-image quality above and below the diagonal we refer to it as a*symmetric matrix*. A correlation matrix is always a symmetric matrix.
To locate the correlation for any pair of variables, find the value in the table for the row and column intersection for those two variables. For instance, to find the correlation between variables C5 and C2, I look for where row C2 and column C5 is (in this case it's blank because it falls in the upper triangle area) and where row C5 and column C2 is and, in the second case, I find that the correlation is -.166.
OK, so how did I know that there are 45 unique correlations when we have 10 variables? There's a handy simple little formula that tells how many pairs (e.g., correlations) there are for any number of variables:
where N is the number of variables. In the example, I had 10 variables, so I know I have (10 * 9)/2 = 90/2 = 45 pairs.

C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C1 1.000 C2 0.274 1.000 C3 -0.134 -0.269 1.000 C4 0.201 -0.153 0.075 1.000 C5 -0.129 -0.166 0.278 -0.011 1.000 C6 -0.095 0.280 -0.348 -0.378 -0.009 1.000 C7 0.171 -0.122 0.288 0.086 0.193 0.002 1.000 C8 0.219 0.242 -0.380 -0.227 -0.551 0.324 -0.082 1.000 C9 0.518 0.238 0.002 0.082 -0.015 0.304 0.347 -0.013 1.000 C10 0.299 0.568 0.165 -0.122 -0.106 -0.169 0.243 0.014 0.352 1.000

*correlation matrix*. It lists the variable names (C1-C10) down the first column and across the first row. The diagonal of a correlation matrix (i.e., the numbers that go from the upper left corner to the lower right) always consists of ones. That's because these are the correlations between each variable and itself (and a variable is always perfectly correlated with itself). This statistical program only shows the lower triangle of the correlation matrix. In every correlation matrix there are two triangles that are the values below and to the left of the diagonal (lower triangle) and above and to the right of the diagonal (upper triangle). There is no reason to print both triangles because the two triangles of a correlation matrix are always mirror images of each other (the correlation of variable x with variable y is always equal to the correlation of variable y with variable x). When a matrix has this mirror-image quality above and below the diagonal we refer to it as a

*symmetric matrix*. A correlation matrix is always a symmetric matrix.
